Metal Building Systems

Ranbuild is a light gauge, cold-formed pre-engineered metal building system ideal for light industrial, commercial, agricultural and multipurpose buildings. Integrated engineering and manufacturing technology provides flexibility and speed in design, delivery and construction.

An optimised design combining strength and safety with cost-effectiveness.
Factory prefabrication for consistent quality and consolidation of full building kit = fast installation on site.

PRODUCT FEATURES

Structural components:

LYSAGHT^® CEE Purlins, Ribbed Channels (C75/C90/C100).
LYSAGHT^® TOPSPAN (TS40/TS61/TS90), Bracing.

Cladding:

LYSAGHT® TRIMDEK® OPTIMA™
*actual components depend on the design and local manufacturing availability.

Design:

RDS™ and RDSe™ integrated design and detailing software, incorporating over 20 years of research & development, including full-scale testing, and feedback from thousands of projects.

Material Range:

Structural:	GALVASPAN^® Galvanized Steel
Coating Mass:	Z275
Thickness:	as per design
Steel Grade:	G300 - G500
Cladding:	BlueScope COLORBOND^® and ZINCALUME^®
Coating Mass:	AZ150
Thickness:	0.35mm, 0.40mm BMT
Steel Grade:	G550

Hardware for Connections:

Hot dipped galvanized bolts and brackets, clips, Class 3 fasteners.

Optional accessories:

Insulation, Transluscent Panels, Ventilators, Windows and Doors.
